WECO ULTRA-300 Whole House Reverse Osmosis Filtration System | Up To 4 Baths
- The whole-house reverse osmosis water filtration system greatly reduces a wide range of contaminants, including sediment, chlorine, chloramine, nitrate, sodium, heavy metals, total dissolved solids (TDS), chromium, fluoride, mercury, radon, benzene, lead, and more.
- Equipped with water pressure sensors and booster pumps, ensuring the filtration system operates at maximum capacity and produces an impressive 4000 gallons per day.
- The system includes a 300-gallon atmospheric water storage tank (blue) with a 16" vented manway (36" diameter x 81" height), featuring a water recirculating ozone sanitizing unit.
- Automated equipment control is facilitated by auxiliary relays, float control units, and an RO controller, eliminating the need for user input.
- Note: Due to high water waste, storage space, and maintenance requirements, this system is not recommended for city water. It is specifically designed for problematic well water. Contact WECO Filters with your water report for a free consultation.
- Operating limits: Hardness < 7 grains, maximum water temperature of 85°F, inlet pressure of 30-80 PSI, incoming TDS of 1000 ppm, removal of hydrogen sulfide, iron, and manganese. Silica < 50 ppm, Turbidity removal, pH range of 3-11. Consultation and free pre-treatment equipment estimates are available for out-of-spec water chemistry.
- The water pressure booster pump, equipped with intelligent controls, ensures optimal water pressure for light commercial applications, water stores, and houses with up to 3 floors and 8 taps.
- Made to order. Contact us for lead time information.
Reverse osmosis is a powerful water purification technology that is particularly effective for treating problematic well water. This advanced filtration method can remove a wide range of contaminants, including fluoride, mercury, salts, lead, radon, benzene, and more. The ULTRA-300 is a state-of-the-art reverse osmosis system designed to address challenging water quality issues, such as high total dissolved solids (TDS) and fluoride.
While the ULTRA-300 is highly efficient, pre-treatment may be necessary for certain water conditions. If you're dealing with challenges like elevated TDS levels, coliform bacteria, hard water, iron staining, iron bacteria, or high silica content, our WQA-certified water specialists can provide expert guidance to optimize your system's performance. They will recommend the appropriate pre-treatment solutions to ensure that your ULTRA-300 operates at its peak efficiency.
2000 gallon per day reverse osmosis water purification system.
Integrated pressure booster pump, commercial grade membranes for easy maintenance, high & low pressure sensors for automated RO control based on tank water level.
- Power: 110V
- Ports: ⅜ in/out, ⅜ drain
- Production: 2000 GPD @ 77 °F theoretical capacity
Coconut Shell Activated Carbon Backwash System
Coconut shell charcoal-based backwash filter unit reduces chemicals that may harm the delicate RO membranes.
Control valve with auxiliary relay communicates with the RO controller to stop the RO when the unit backwash and drain.
300 Gallon Atmospheric with Automated Daily Ozone Feed
Tank retrofitted with a post treatment recirculation loop that keeps the treated water fresh.
- Ports: 1½ Inch Inlet & 2 Inch Outlet NPT
- Tank Dimensions: ~36x36x85"
Intelligent Distribution Pump
Ultra low noise. No vibrations. Reduced energy consumption.
- Horizontal or vertical installation. P1 Max: 1hp (850W)
- Ports: 1" FNPT
- H Max: 79 psi
- Flow Rates: ~1-15 GPM
- Pressure: 5 GPM @ 50 PSI/10 GPM @40 PSI
Distribution Pump Dimensions: ~11x10x18" Intuitive LCD display interface provides access to all information, giving the possibility of customizing the main settings.
Your Complete Water Solution
To ensure consistent water pressure throughout your home, the ULTRA-300 incorporates a fully integrated water booster pump. This compact unit includes a pump, motor, tank, sensor, drive, and non-return valve, making installation quick and easy. With its intelligent pump control, the booster pump adjusts its performance to meet your specific water demands, ensuring a reliable and steady water supply.
The ULTRA-300's booster pump is designed to provide maximum comfort with minimal effort. It operates quietly, ensuring a peaceful home environment. By combining advanced reverse osmosis technology with a reliable booster pump, the ULTRA-300 offers a comprehensive solution for delivering clean, high-quality water to your home.
- Purified water at all faucets, hose bibs, showers, ice makers throughout the house.
- Filters 99% of contaminants such as sediment, total dissolved solids (TDS), nitrate, chromium, lead, copper, mercury, cadmium, sodium, fluoride, arsenic, chloride & many more.
- Four booster pumps maintain the water pressure optimal for the RO membranes.
- Standard commercial type RO membranes. Easy to replace. Time tested results.
- Water storage for daily needs of up to 4 people.
Commercial RO Membranes
Our engineering team can analyze your well water report and provide computer simulations of RO permeate water chemistry. This service is offered at no cost, both before and after your purchase.
Standard Features
Membrane Elements
Filter Housings
Membrane Housings
Flow Control
Filter Cartridges
Fittings
RO Specifications
| Model | System Capacity | Membrane Elements | Standard Recovery | Nominal TDS Rejection | Dimensions L x W x H in | Shipping Weight lbs (kg) | ||
|---|---|---|---|---|---|---|---|---|
| GPD | LPD | Size | Quantity | |||||
| XLH-4000 | 4,000 | 15,141 | 4040 | 2 | 40% | 97% | 33 x 33 x 132 | 127 |
Atmospheric Storage Tank Specifications
| Model | Tank Capacity | Inlet Port | Outlet Port | Dimensions L x W x H in | Shipping Weight lbs | |
|---|---|---|---|---|---|---|
| GPD | LPD | |||||
| ATMOS-300BU | 300 | 1,136 | 1½-Inch Bulkhead NPT | 2-Inch Bulkhead NPT | 36 x 36 x 85 | 80 |
Pump Specifications
| Model | Power | Q Max | H Max | Dimensions L x W x H in |
|---|---|---|---|---|
| DAB MINI SYS 3 | 1 hp (850 W) | 22 GPM | 79 PSI | 17 ½ x10 ½ x9 ½ |
Backwash Filter Specifications
| Model | Service Flow | Backwash Flow | Port Fittings | Drain Fittings | Dimensions |
|---|---|---|---|---|---|
| ACX-1054 | 6 gpm | 3 gpm | 1-inch MNPT | ½-inch MNPT | 10 x 10 x 65 inches |
Whole House RO is ONLY Recommended for Problematic Well Water
- Test your water source. Check the water chemistry and identify the impurities you need addressed. Talk with a water professional and choose other options if available. You can always do reverse osmosis under the kitchen sink just for drinking water. We have an excellent range of under sink RO systems
- If you absolutely need to do whole house reverse osmosis, please do your research about the ups and downs of whole house RO.
1 to 1 Product to Waste Under Test Conditions*
- Try to recycle waste water. RO system will waste 1 gallon for every 1 gallon purified. Store the waste and recycle for flushing the toilets, gardening...etc. Talk with your plumber to identify ways to conserve water.
- Neutralize pH: Treated water may be 1-2 pH points below feed water.
- Use a lab for obtaining a comprehensive drinking water analysis of your untreated well water.
- Pre-treat the water if needed.
Pre-treatment may include water softening. backwash filters for iron/manganese reduction, chemical injection for high TDS/silica and other treatment as required by the specific feed water chemistry.
*Conditions: 250 ppm softened municipal water @ 77 °FO
Replacement Filters / Parts
RO Membranes
4040 Low Energy Membranes x 2 (~2 years on municipal water or pre-treated well water)
RO Pre-Filter
4520 Sediment Filter (Replace every 6 months)
Check Valve
316-CV-OZ (every 12 months)
Cleaning Kit
OZCLEAN-KIT (every 12 months)
| UPC | 670087221720 |
|---|
